The USMT-SD3070 is a three-sided LED truck built on a Foton Times Xiangling V chassis with a 10-foot wheelbase, delivering screens on the left, right, and rear from a compact 16’11” x 5’7″ x 8’7″ truck body. Left and right screens are each 8’4″x5’2″, and the rear adds a 3’1″x4’8″ panel, all in P3, P4, or P5 pixel pitch. The hydraulic lift reaches 4’11”, and wind resistance holds to Level 8 at that height. An 8’6″x3’11″x2’3″ stage extends from the vehicle for activations, and an 8KW generator at 220V powers the full system. At a compact weight and shipping in a 40OT container, this is a three-sided truck suited for operators who need multi-directional display coverage in a smaller, more maneuverable vehicle.
Key Features / Benefits
- Three-sided LED display: left 8’4″x5’2″, right 8’4″x5’2″, rear 3’1″x4’8″ with P3, P4, or P5 pixel pitch
- Hydraulic lift to 4’11” with Level 8 wind resistance at deployment height
- 8’6″x3’11″x2’3″ stage for live events and brand activations
- Foton Times Xiangling V chassis with 10-foot wheelbase for compact maneuverability
- 220V/8KW generator power for self-contained on-site operation
- Computer display content management
- Ships professionally packed in a 40′ OT container
Technical Specifications
| Specification | Details |
|---|---|
| Truck Body Size | 16’11″x5’7″x8’7″ |
| Screen Size (Left Side) | 8’4″x5’2″, Dot Pitch: P3/P4/P5 |
| Screen Size (Right Side) | 8’4″x5’2″, Dot Pitch: P3/P4/P5 |
| Screen Size (Rear Side) | 3’1″x4’8″, Dot Pitch: P3/P4/P5 |
| Hydraulic | Lifting range 4’11” |
| Stage | 8’6″x3’11″x2’3″ |
| Wind Resistance | Against Level 8 wind after screen lifts up 4’11” |
| Wheel Base | 10 ft |
| Chassis Brand | Foton Times Xiangling V |
| Power Supply | 220V/8KW generator power |
| Kinds of Play | Computer display |
| Packing | Professional packing with fixed in container |
| Container | 40OT |
| HS Code | 8705909990 |
