The USMT4 Scooter Advertising Trailer is a three-sided LED display unit designed to be towed by a scooter or small vehicle, making it one of the most compact and maneuverable advertising platforms in the lineup. The left and right screens are each 3’1″x4’8″, and the rear adds a 2’1″x4’8″ panel, all available in P3, P4, or P5 pixel pitch. Two 12V 200AH batteries totaling 4.8KWH power the system without any external supply or generator, and a 500KG torsion shaft with a 1.9″ ball head four-hole impact connector handles the trailer connection. Content loads via USB flash drive or remote display. At 4’11″x4’1″x6’8″ and shipped nude packed in a 20GP container, this is an accessible, low-footprint option for street-level outdoor advertising in pedestrian zones, markets, and event circuits.
Key Features / Benefits
- Three-sided LED display: left 3’1″x4’8″, right 3’1″x4’8″, rear 2’1″x4’8″ with P3, P4, or P5 pixel pitch
- Battery powered with 12V 200AH x 2 (4.8KWH total); no generator or shore power needed
- 500KG torsion shaft (4-114.3, 1 pc) with 1.9″ ball head four-hole impact connector
- USB flash drive and remote display for content management
- Compact at 4’11″x4’1″x6’8″ for scooter towing and narrow-space access
Technical Specifications
| Specification | Details |
|---|---|
| Trailer Size | 4’11″x4’1″x6’8″ |
| Screen Size (Left Side) | 3’1″x4’8″, Dot Pitch: P3/P4/P5 |
| Screen Size (Right Side) | 3’1″x4’8″, Dot Pitch: P3/P4/P5 |
| Screen Size (Rear Side) | 2’1″x4’8″, Dot Pitch: P3/P4/P5 |
| Torsion Shaft | 500KG 4-114.3, 1 pc |
| Module Size | 1′(W) x 6″(H) |
| Battery Specifications | 12V 200AH, 2 pcs / 4.8KWH |
| Connector | 1.9″ ball head, 4-hole impact connector |
| Kinds of Play | USB flash disk play, remote display |
| Packing | Nude packing with fixed in container |
| Container | 20GP |
| HS Code | 8716800000 |
